Win32 | Steven Engelhardt

Win32 c win32

Published: 2008-06-12

In the Windows XP login screen, the password text box will warn you with a balloon tooltip if you accidentally turn Caps Lock on. The balloon tooltip appears to be a Windows tooltip common control with the TTS_BALLOON style.

To replicate this functionality, I decided to write a function called ShowMsgBalloon() which, given a control and the various balloon tooltip parameters, creates and shows the balloon tooltip below the control.

Custom-Drawn Win32 Tooltips

Win32 c win32

Published: 2007-08-29

Like many common controls, the tooltip control supports custom drawing for maximum flexibility. This is a quick tutorial on how to use the tooltip custom draw facility.

First, start with the following scratch program (which is a slightly modified version of Raymond Chen’s scratch program):

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95


#define STRICT
#include <windows.h>
#include <windowsx.h>
#include <commctrl.h>
#include <tchar.h>

#define WND_CLASS_NAME TEXT("Scratch")

HINSTANCE g_hinst;

BOOL OnCreate(HWND hwnd, LPCREATESTRUCT lpcs)
{
    return TRUE;
}

void OnDestroy(HWND hwnd)
{
    PostQuitMessage(0);
}

LRESULT CALLBACK WndProc(HWND hwnd, UINT uiMsg, WPARAM wParam,
                         LPARAM lParam)
{
    switch (uiMsg)
    {
    HANDLE_MSG(hwnd, WM_CREATE, OnCreate);
    HANDLE_MSG(hwnd, WM_DESTROY, OnDestroy);
    }

    return DefWindowProc(hwnd, uiMsg, wParam, lParam);
}

BOOL RegisterWindowClass()
{
    WNDCLASS wc;
    ATOM atom;

    wc.style = 0;
    wc.lpfnWndProc = WndProc;
    wc.cbClsExtra = 0;
    wc.cbWndExtra = 0;
    wc.hInstance = g_hinst;
    wc.hIcon = NULL;
    wc.hCursor = LoadCursor(NULL, IDC_ARROW);
    wc.hbrBackground = (HBRUSH)(COLOR_WINDOW + 1);
    wc.lpszMenuName = NULL;
    wc.lpszClassName = WND_CLASS_NAME;

    atom = RegisterClass(&wc);
    return (atom != 0);
}

int WINAPI _tWinMain(HINSTANCE hinst, HINSTANCE hinstPrev,
                     LPTSTR lpCmdLine, int nCmdShow)
{
    INITCOMMONCONTROLSEX icc;
    int ret = EXIT_FAILURE;

    g_hinst = hinst;

    // We will need the tooltip common control
    icc.dwSize = sizeof(icc);
    icc.dwICC = ICC_WIN95_CLASSES;
    if (InitCommonControlsEx(&icc))
    {
        if (RegisterWindowClass())
        {
            HWND hwnd = CreateWindow
                (
                WND_CLASS_NAME,
                TEXT("Scratch"),
                WS_OVERLAPPEDWINDOW,
                CW_USEDEFAULT, CW_USEDEFAULT,
                CW_USEDEFAULT, CW_USEDEFAULT,
                NULL,
                NULL,
                hinst,
                );
            if (hwnd != NULL)
            {
                MSG msg;

                (void) ShowWindow(hwnd, nCmdShow);
                while (GetMessage(&msg, NULL, 0, 0)) {
                    TranslateMessage(&msg);
                    DispatchMessage(&msg);
                }

                ret = EXIT_SUCCESS;
            }
        }
    }

    return ret;
}

Next, we’ll add a tooltip to this window. We’re not going to do anything fancy like tooltip multiplexing so we’ll use TTF_SUBCLASS.

Win32: Getting LOGFONT from HFONT

Win32 win32

Published: 2007-08-22

To convert a HFONT to a LOGFONT, use the GDI function GetObject(), as in:

1
2
3


LOGFONT lf;
int ret = GetObject(hfont, sizeof(lf), &lf);
// Be sure to check the return value of GetObject

The code is trivial but the function took me forever to find.

Vista Does Not Virtualize Creation Of Shell Links

Win32 vista win32

Published: 2007-05-24

Vista Does Not Virtualize Creation Of Shell Links

Windows Vista developers beware: Vista does not perform file virtualization on the creation of shell links. Consider the following code:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43


// Creates a shell link (a.k.a. shortcut) located at swzLinkFile that points to
// szTargetFile with a description of szDescription.
BOOL CreateLink(LPCTSTR szTargetFile, LPCTSTR szDescription, LPCOLESTR swzLinkFile)
{
    BOOL bRet = FALSE;

    IShellLink* psl;
    HRESULT hr = ::CoCreateInstance(CLSID_ShellLink, NULL, CLSCTX_INPROC_SERVER,
                                    IID_IShellLink, (void**) &psl);
    if (SUCCEEDED(hr))
    {
        IPersistFile* ppf;
        hr = psl->QueryInterface(IID_IPersistFile, (void**) &ppf);
        if (SUCCEEDED(hr))
        {
            hr = psl->SetPath(szTargetFile);
            if (SUCCEEDED(hr))
            {
                hr = psl->SetDescription(szDescription);
                if (SUCCEEDED(hr))
                {
                    hr = ppf->Save(swzLinkFile, TRUE);
                    if (SUCCEEDED(hr))
                    {
                        bSuccess = TRUE;
                    }
                }
            }
            ppf->Release();
        }
        psl->Release();
    }
    return bSuccess;
}

// NOTE: Hardcoding C:\WINDOWS and C:\Program Files is a bad practice. Use
// something like ::SHGetFolderPath().
BOOL bSuccess = CreateLink
    (
    _T("C:\\WINDOWS\\SYSTEM32\\SOL.EXE"),
    _T("Shortcut to SOL.EXE"),
    L"C:\\Program Files\\sol.lnk")
    );

One might expect that the creation of the file C:\Program Files\sol.lnk would be silently redirected by Vista using file virtualization and CreateLink() would succeed, but it doesn’t — the call to IPersistFile::Save() returns E_ACCESSDENIED.

Win32 c debugging win32

Published: 2007-04-25

Debugging Crashes in Windows Applications: The Null Pointer Dereference

Windows C++ developers remain all too familiar with the standard Windows crash dialog. This post is an attempt to teach developers how to understand the data the crash dialog reports to diagnose difficult issues. A basic understanding of assembly language is assumed; for more background on these topics please read Matt Pietrek’s “Under The Hood” articles in the Microsoft Systems Journal February 1998 and June 1998 issues.

To begin with, let’s write an application that crashes with a null pointer dereference:

Win32 compression win32

Published: 2007-03-12

Delta Compression Application Programming Interface

Apparently Microsoft has an API for just about everything. Today I read about Microsoft’s Delta Compression Application Programming Interface, an API for creating and applying binary diffs. This API looks ideal for building an application’s incremental online update facility.

Win32 Shell Lightweight Utility API (shlwapi.dll)

Win32 win32

Published: 2007-02-01

The Win32 shell lightweight utility API (shlwapi.dll) is a cornucopia of useful functions. It appears to be Microsoft’s “dumping ground” for functions without a better home. (I believe Microsoft internal DLL ownership also played a part.) Had I known about shlwapi years ago, it would have saved me considerable programming effort.

Particularly useful are SHCreateStreamOnFile, the path family of functions (e.g. PathCombine), and the registry family of functions (e.g. SHRegGetPath).

However, it appears that Microsoft is slowly moving functionality out of shlwapi into other places. For example, many of shlwapi’s string handling functions have better-designed replacements in Microsoft’s safe string library strsafe. Similarly, shlwapi’s SHRegGetValue has been deprecated in favor of advapi32.dll’s RegGetValue.

Win32 c mfc win32

Published: 2005-09-08

Beware File Open/Save Dialogs: They May Change The Current Directory

On some Windows operating systems (primarily Windows 95, 98, and ME), GetOpenFileName() and GetSaveFileName() (and wrappers of these functions such as MFC’s CFileDialog) will permanently change the process’s current working directory unless the OFN_NOCHANGEDIR option is specified. As you can imagine, this can easily break your application if you ever rely on the current working directory being set to a particular value (such as if you open files using relative paths).

Of course, it is best to eliminate any such current working directory assumptions from your application completely.
